224-310KW康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电量用启因素燃料市场可持续性好: 现代化的燃料管理整体的，具有的STC、ESTC 级别划分管理整体的，专项 设汁的柱塞上端烧燃室，低压喷洒燃料，充沛雾化吸入，烧燃充沛。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯来发电用打火机瞬态性优异的: 非凡的打火机整体风格来设计，相互配合康明斯个性的EFC体统，的控制精密度较高，崩溃时长快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯来发电用启驱力升马力高: 总体装修设计紧凑型轿车.样貌流程合理的，运营平缓。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷cpu型号 QSNT. QSK19. QSK38. QSK50符合中国有非路面3价段及中美洲Tier2. Tier 3排污法律的要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备件管理即得性好， 汽车发动因运营及维持护肤保养快捷，生产成本费用较低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

瓦数规模 Power Range   224-310KW连接结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L样貌寸尺 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净质 Dry Weight   940kg

224-310KW康明斯发电量用打着机的优势特点：重量小， 缩小变高， 防雨百叶气氛微波加热，更易启动的，中国电信车截电原的最佳的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

热车机规格	常常用输出(kW)Prime Power	后备电源马力kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
